BMGeoIP follows CMDB’s standalone HTTP server and systemd installation pattern. The web interface listens on 0.0.0.0:54300 by default and renders HTML with Jinja2, with automatic HTML escaping. The dark blue and teal interface follows CMDB’s header, panels, tables, and schedule controls. It configures cron downloads of the IPv4 and IPv6 CSVs and shows their paths, modification times, and sizes. GeoIP lookups and ZMQ messaging are not implemented yet.

Installation

Use Python 3.11 or later with virtual-environment support and systemd. On Debian/Ubuntu, install the prerequisites:

sudo apt install python3 python3-venv cron

From a checkout separate from /opt/prod/bmgeoip, run:

sudo scripts/install.sh

The installer creates the bmgeoip system account with a nologin shell, copies application files and the logo to /opt/prod/bmgeoip, and installs Jinja2 and python-crontab in /opt/prod/bmgeoip/.venv. It runs the Python tests, verifies the systemd unit, enables bmgeoip-server.service at boot, starts it, and checks the health endpoints and rendered home page. It also enables the Debian/Ubuntu cron.service. The process runs as bmgeoip with a private temporary directory and a read-only system filesystem, except for its state directory and the cron spool. StateDirectory=bmgeoip creates /var/lib/bmgeoip. The systemd unit allows the setgid crontab helper, following CMDB’s service configuration. No database is required for this web server foundation.

Open http://<server>:54300/. The interface has no authentication and is intended for a trusted LAN. Installation does not change firewall rules.

Rerun the installer from an updated checkout to update the service. It stops an existing service before updating dependencies and files. If installation fails, fix the reported error and rerun it; automatic rollback is not provided.

Endpoints and operations

GET and HEAD are supported on page, asset, and health routes. Schedule POSTs require Content-Type: application/json and a body of at most 4096 bytes. Invalid settings return HTTP 400, cross-origin saves return HTTP 403, and storage or cron failures return HTTP 503. Settings are restored if writing the crontab fails. Unknown paths return HTTP 404 with {"error":"Not found."}. Requests have a ten-second socket timeout. SIGTERM and Ctrl-C stop the server cleanly; systemd restarts failed processes.

systemctl status bmgeoip-server.service
journalctl -u bmgeoip-server.service -f
curl -i http://127.0.0.1:54300/health
curl -i http://127.0.0.1:54300/ready
sudo systemctl restart bmgeoip-server.service

CSV download schedule

Use the Enabled checkbox, enter five cron fields, and click Update. The initial schedule is disabled; its suggested expression 0 3 * * 0 means Sunday at 03:00 in the server’s local timezone. Cron also supports ranges, lists, and steps. Disabling and saving removes BMGeoIP’s cron entry without removing unrelated jobs. The settings persist in /var/lib/bmgeoip/download-schedule.json and survive service restarts and installer updates.

The service account’s cron job runs /opt/prod/bmgeoip/bmgeoip-download.py using the installed virtual environment. It works independently of the HTTP server, rechecks the saved enabled flag, and skips overlapping invocations. An in-progress download finishes if the schedule is disabled. Logs append to /var/lib/bmgeoip/download.log.

Each family is downloaded and validated independently, so one failure does not prevent the other family from refreshing. Failed downloads preserve the previous usable CSV. Reload the webpage to refresh file status; modification times display in UTC. Provider, path, and default expression settings live in bmgeoip/constants/DGeoIp.py. There is no database import yet.

sudo crontab -u bmgeoip -l
tail -n 50 /var/lib/bmgeoip/download.log

Development

The Python runtime is separate from the GitHub Pages documentation site:

python3 -m venv .venv
.venv/bin/python -m pip install -r requirements.txt
.venv/bin/python -B -m unittest discover -s tests -v
.venv/bin/python -B bmgeoip-server.py --host 127.0.0.1 --port 54300

Runtime defaults and installation paths are in bmgeoip/constants/DBMGeoIP.py. --host accepts an IPv4 address; --port accepts integers from 1 to 65535. The service uses these defaults. The handler owns HTTP routes, while bmgeoip/server/BMGeoIPServer.py owns startup and shutdown. Templates live in bmgeoip/server/templates/ and web assets in bmgeoip/server/static/.
